Item no. |
Model | Dimensions | Power consumption |
Voltage | Nominal current |
for rooms |
Weight | Certificates |
50488 | SIKU IPP 320 SW | 600 x 600 x 12 mm | 320 W | 230 V / 50 Hz | 1,5 A | up to 5 m² | 7,0 kg | RoHS, CE |
50489 | SIKU IPP 580 SW | 600 x 1000 x 12 mm | 580 W | 230 V / 50 Hz | 2,5 A | up to 10 m² | 11,2 kg | RoHS, CE |
50490 | SIKU IPP 700 SW | 600 x 1200 x 12 mm | 700 W | 230 V / 50 Hz | 3,0 A | up to 13 m² | 13,25 kg | RoHS, CE |
Surface: white satin glass
Rear material: Aluminium
Frame: without frame
Heating element: Carbon Crystal
Surface temperature: 70-90°C
Overheating protection: Yes
Electical efficiency: 98%
Protection class: IP54
Cable length: 1.9 m
Mounting: Wallmounting
Guarantee: 2 years
Download:
Manual SIKU Infraplate pro Satinato
Data sheet SIKU Infraplate pro Satinato
